Rental Lift access system

Name: st access
Address: MY
Telephone: 0122199195

Monthly RM500 per lift

Taiwan technology since 2000 , Anti-copy (no clone card) , lightning damage under warranty , 1:1 exchange , individual floor control , complete work no hidden cost.....

Learn More

Home: Welcome

ST access

ST Story

Since being established in 2000, st access has been known for an unparalleled commitment to customer satisfaction. It’s this standard of excellence that has provided the impetus for us to grow into the business we are today.

We believe that the customer always comes first - and that means exceptional products and exceptional services. Get in touch today to learn more about what we have to offer.

Home: About

ST Products

Best of the Best

Home: Products

ST-1380MF / ST-1300MF

FEATURES

S1, S2, S3 mode switch for different requirement.
144 x 64 LCD Display and 16 keys with White Backlight.
Automatic switch Attendance sections.
16 keys with white backlight.
Built-in 2 relays for open door and external output (24V/5A).
Built-in a reader and an external reader port for exit or anti-pass-back.
Alarm Function is available(tamper, Force entrance, Door open too long, Duress).
Dual function to control Electric locks and setting security machine.
Use Master Card or Master Code to enter edit mode for easy and quickly setting.
Keypad will be locked for 30 seconds while continuous error operation.
Door unlock time setting, latched-on/latched-off or momentary 0.1-600 seconds.
Reading ISO14443a type Mifare smart card serial numbers.
Card can be added/deleted/inquired by key-in or read-learn-in directly or PC/Laptop.
Doors unlock time setting, Latched-on/latched-off or momentary 0.1-600 Seconds.
Individual System Code and Anit-Copy by Mifare Programmer.

ST-1200MF

FEATURES

S1, S2, S3 mode switch for different requirement.
13 keys with white backlight.
An Independent button for connect to door bell.
Built-in 2 relays for open door and external output (24V/5A).
Built-in a reader and an external reader port for exit or anti-passback.
Alarm Function is available (tamper, Force entrance, Door open too long, Duress).
Dual function to control Electric locks and setting security machine.
Use Master Card or Master Code to enter edit mode for easy and quickly setting.
Keypad will be locked for 30 seconds while continuous error operation.
Door unlock time setting, latched-on/latched-off or momentary 0.1-600 seconds.
Reading ISO14443a type Mifare smart card serial numbers.
Card can be added/deleted/inquired by key-in or read-learn-in directly or PC/Laptop.
Doors unlock time setting, Latched-on/latched-off or momentary 0.1-600 seconds.
Individual System Code and Anti-Copy by Mifare Programmer.

ST-FL16

FEATURES

16 sets output , Can choose NO or NC
16 LED, 16 sets control point
Connect with RS485
16 sets control point of floor. It can be simultaneously connected with maximum of 16 elevator controllers for any buildings which exceed 256 floors.

SPECIFICATIONS

Model : ST-FL16(Elevator Controller)

Hand Control : 1 Set hand control

Output : 16 Sets Relay Output (Can be set NO or NC)

Indicators : 16 LEDs

Interface : RS485

Expansion: Max to 256 Floor (16 Controllers)

Waiting time : 0 ~ 255 seconds

Open Period : Each day of a week can set 2 open periods.

Board Dimensions (mm) : 130(H) x 100(W) x 17(D)mm

Box Dimensions (mm) : 305(H) x 245(W) x 120(D)mm

Power Input : 12 VDC

Operating Temperture : -5°C ~ 60°C

Operating Humidity :

5% ~ 95% (Non-condensing)

ST-1100RMF

Mifare anti-copy indoor Reader
support wiegand output
12VDC - 500mA

ST-USB485

FEATURE

Suitable All Windows Version [Include Win10]
Transmission speed up to 1Mbps
Support hot plug

ST-IP100A

FEATURE

Serial Port
　　Baud Rate : 300~230.4k bps　　Parity : None、Odd、Even
　　Data Bit : 5、6、7、8 　　　　Stop Bit : 1、2
Watch Dog function
Software update by network

ST-916

FEATURES

Ethernet interface is Optional, for connecting to LAN or internet; Supports TCP,UDP, DHCP protocol.
Can specify different effective passage period for everyone.
Built-in 3 Watching Dog. (Timing, voltage and pulse detection)
With self-detection device to prevent the system and the CPU to crash.
Support alert settings and release schedule.
Support door open/close schedule.
With 4 relay outputs to control devices or alarm clock by from readers.
With two external WG interface to connect Readers.
Supports alarm output when device is disconnected.
4 digital inputs support release all doors function in case of emergency.
Data and timer can be kept more than 60 days after power down.
63 Time Zones can be set up holidays and combine with other time zones.
Support alarm output when violate the anti-passback.
Each user can be set to allow to enter/exit assigned doors with 16 sets anti-pass-back function.
Built-in power and data transmission LED indicators for debugging and status.
